GPS-4303 Linear DC Power Supply

Brief description

The GPS-Series are 2Channel- to 4-Channel, 180 to 200W output , linear DC power supply. Overload and reverse polarity protection and output on/off switch keep the GPS-Series and their load safe from unexpected conditions. A High regulation (0.01%+3mV) and low ripple / noise (< 1mVrms ,5Hz -1MHz) are maintained for channel 1 and 2 in constant voltage mode. Automated cooling fan speed control minimizes fan noise according to load conditions,ensuring quiet operation.The GPS-Series are an ideal solution for lightweight, inexpensive bench-top or portable applications requiring high regulation and multiple outputs.

Properties

• 2 Independent Isolated Output
• Four "3 Digits" LED Displays
• 0.01% Load and Line Regulation
• Low Ripple and Noise
• Tracking Operation and Auto Series/Parallel Operation
• Output ON/OFF Switch
• Fan Speed Control Circuit to Minimize Fan Noise
• Over Load and Reverse Polarity Protection
• Optional European Jack Type Terminal

Technical attributes:
